Theater

multipurpose hall

Church

Karaoke

Front Zone and Delayed Fill-in

1、Excellent vocal performance

2、3"Phase Correction HF compression driver,Double curvature high-frequency waveguide  coupling structure, eliminating phase interference at cross-frequency points

3、Low frequency response extend to 40Hz

4、With CPS (Coaxial Point Source) technology

Technical Specification

Frequency Response

Nominal directivity(-6dB)

Sensitivity(@1w/1m)

Power Rating

Impedance

Maximum SPL

Transducers

50Hz~18kHz(±3dB),40Hz~20kHz(-10dB)

40°(H)x60°(V)

103dB SPL

500W

8 ohm

130dB/140dB SPL peak

LF:1x15" All Condition Woofer

HF:1x3"Phase Correction HF compression driver

Power Input

Connectors

Speaker Cables

NEUTRIK NL4MP*2

1+1-

Physical Data

Dimensions

Weight

Material

Finish

Installati on

Grille

440x432x580mm

21kg

Imported multi-plywood Environmental waterproof and anti-corrosion coatings

Black Polyurea paintings

M8 Lifting Point + 35mm Support Base

DPR(Double Perforation Rate )technology design, in which theperforation rate of the middle and high transmission area ismore than 90%,Greatly improves the sound transmissionefficiency and reduces the acoustic crosstalk of the surfacegrid.
